Formwork

Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles

SKU
FMLS60
In stock
$1,201.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Antique Brass Antique Brass
  • Antique Copper Antique Copper
  • Architectural Bronze Architectural Bronze
  • Burnished Brass Burnished Brass
  • Burnished Nickel Burnished Nickel
  • Carbon Carbon
  • Chrome Chrome
  • Gold Gold
  • Matte Gold Matte Gold
  • Matte Nickel Matte Nickel
  • Nickel Nickel
  • Pewter Pewter
  • Shiny Copper Shiny Copper
  • Sovereign Sovereign
  • Unlacquered Brass Unlacquered Brass
  • Vintage Brass Vintage Brass

+

{"31348":{"price":"$1,321.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Nickel","price_gtm":"1321.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Nickel","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-20462-81497","default":true,"id":"31348"},"31355":{"price":"$1,395.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Matte Nickel","price_gtm":"1395.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Matte Nickel","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-88644-67438","default":false,"id":"31355"},"43351":{"price":"$1,651.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Pewter","price_gtm":"1651.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Pewter","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-41565-73263","default":false,"id":"43351"},"43350":{"price":"$1,598.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Burnished Brass","price_gtm":"1598.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Burnished Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-39990-18156","default":false,"id":"43350"},"31345":{"price":"$1,652.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Sovereign","price_gtm":"1652.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Sovereign","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-03195-33519","default":false,"id":"31345"},"31353":{"price":"$1,717.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Carbon","price_gtm":"1717.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Carbon","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-18865-30843","default":false,"id":"31353"},"31350":{"price":"$1,652.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Antique Copper","price_gtm":"1652.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Antique Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-46492-87547","default":false,"id":"31350"},"31354":{"price":"$1,601.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Burnished Nickel","price_gtm":"1601.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Burnished Nickel","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-84307-38244","default":false,"id":"31354"},"31357":{"price":"$1,652.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Antique Brass","price_gtm":"1652.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Antique Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-09439-59702","default":false,"id":"31357"},"31352":{"price":"$3,302.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Gold","price_gtm":"3302.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-01526-63822","default":false,"id":"31352"},"31351":{"price":"$1,652.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Shiny Copper","price_gtm":"1652.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Shiny Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-55892-06174","default":false,"id":"31351"},"31346":{"price":"$3,315.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Matte Gold","price_gtm":"3315.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Matte Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-28757-98855","default":false,"id":"31346"},"43352":{"price":"$1,651.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Vintage Brass","price_gtm":"1651.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Vintage Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-54249-19764","default":false,"id":"43352"},"31349":{"price":"$1,652.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Architectural Bronze","price_gtm":"1652.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Architectural Bronze","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-24269-48655","default":false,"id":"31349"},"31356":{"price":"$1,344.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Unlacquered Brass","price_gtm":"1344.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Unlacquered Brass","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-65435-91392","default":false,"id":"31356"},"31347":{"price":"$1,201.00","price_unit":"Each","name":"Formwork Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Knob Handles in Chrome","price_gtm":"1201.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Formwork","variant":"Metal Finish:Chrome","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-23655-23063","default":false,"id":"31347"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["31347"],"for_sale":0,"price":1201},{"id":"5","label":"Nickel","products":["31348"],"for_sale":0,"price":1321},{"id":"19","label":"Unlacquered Brass","products":["31356"],"for_sale":0,"price":1344},{"id":"6","label":"Matte Nickel","products":["31355"],"for_sale":0,"price":1395},{"id":"495","label":"Burnished Brass","products":["43350"],"for_sale":0,"price":1598},{"id":"406","label":"Burnished Nickel","products":["31354"],"for_sale":0,"price":1601},{"id":"450","label":"Pewter","products":["43351"],"for_sale":0,"price":1651},{"id":"672","label":"Vintage Brass","products":["43352"],"for_sale":0,"price":1651},{"id":"14","label":"Antique Brass","products":["31357"],"for_sale":0,"price":1652},{"id":"13","label":"Antique Copper","products":["31350"],"for_sale":0,"price":1652},{"id":"8","label":"Architectural Bronze","products":["31349"],"for_sale":0,"price":1652},{"id":"17","label":"Shiny Copper","products":["31351"],"for_sale":0,"price":1652},{"id":"18","label":"Sovereign","products":["31345"],"for_sale":0,"price":1652},{"id":"249","label":"Carbon","products":["31353"],"for_sale":0,"price":1717},{"id":"15","label":"Gold","products":["31352"],"for_sale":0,"price":3302},{"id":"16","label":"Matte Gold","products":["31346"],"for_sale":0,"price":3315}],"position":"0"}},"optionProducts":{"143":{"6":["31355"],"13":["31350"],"16":["31346"],"5":["31348"],"249":["31353"],"17":["31351"],"3":["31347"],"18":["31345"],"15":["31352"],"19":["31356"],"495":["43350"],"14":["31357"],"8":["31349"],"450":["43351"],"406":["31354"],"672":["43352"]}},"template":"$<%- data.price %>","optionPrices":{"31348":{"oldPrice":{"amount":"1321"},"basePrice":{"amount":"1321"},"finalPrice":{"amount":"1321"}},"31355":{"oldPrice":{"amount":"1395"},"basePrice":{"amount":"1395"},"finalPrice":{"amount":"1395"}},"43351":{"oldPrice":{"amount":"1651"},"basePrice":{"amount":"1651"},"finalPrice":{"amount":"1651"}},"43350":{"oldPrice":{"amount":"1598"},"basePrice":{"amount":"1598"},"finalPrice":{"amount":"1598"}},"31345":{"oldPrice":{"amount":"1652"},"basePrice":{"amount":"1652"},"finalPrice":{"amount":"1652"}},"31353":{"oldPrice":{"amount":"1717"},"basePrice":{"amount":"1717"},"finalPrice":{"amount":"1717"}},"31350":{"oldPrice":{"amount":"1652"},"basePrice":{"amount":"1652"},"finalPrice":{"amount":"1652"}},"31354":{"oldPrice":{"amount":"1601"},"basePrice":{"amount":"1601"},"finalPrice":{"amount":"1601"}},"31357":{"oldPrice":{"amount":"1652"},"basePrice":{"amount":"1652"},"finalPrice":{"amount":"1652"}},"31352":{"oldPrice":{"amount":"3302"},"basePrice":{"amount":"3302"},"finalPrice":{"amount":"3302"}},"31351":{"oldPrice":{"amount":"1652"},"basePrice":{"amount":"1652"},"finalPrice":{"amount":"1652"}},"31346":{"oldPrice":{"amount":"3315"},"basePrice":{"amount":"3315"},"finalPrice":{"amount":"3315"}},"43352":{"oldPrice":{"amount":"1651"},"basePrice":{"amount":"1651"},"finalPrice":{"amount":"1651"}},"31349":{"oldPrice":{"amount":"1652"},"basePrice":{"amount":"1652"},"finalPrice":{"amount":"1652"}},"31356":{"oldPrice":{"amount":"1344"},"basePrice":{"amount":"1344"},"finalPrice":{"amount":"1344"}},"31347":{"oldPrice":{"amount":"1201"},"basePrice":{"amount":"1201"},"finalPrice":{"amount":"1201"}}},"prices":{"oldPrice":{"amount":"1201"},"basePrice":{"amount":"1201"},"finalPrice":{"amount":"1201"}},"productId":"47457","chooseText":"Choose an Option","images":[],"index":{"31348":{"143":"5"},"31355":{"143":"6"},"43351":{"143":"450"},"43350":{"143":"495"},"31345":{"143":"18"},"31353":{"143":"249"},"31350":{"143":"13"},"31354":{"143":"406"},"31357":{"143":"14"},"31352":{"143":"15"},"31351":{"143":"17"},"31346":{"143":"16"},"43352":{"143":"672"},"31349":{"143":"8"},"31356":{"143":"19"},"31347":{"143":"3"}}}
Request Information

Item Details

  • Formwork COLLECTION

    Sculptural forms that defy the ordinary. Unexpected geometry and the transition of the planes create a subtle but warm expression.

  • FEATURES
    • Knob Handles
    • Modern Push-Touch Euro style drain included.
    • Standard flow rate is 2.2gpm (8.3 L/min) and State of California requires 1.2gpm(4.5 L/min). Also available in other flow options. Contact a sales associate for details.
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • Care and Cleaning Summary: Wash surfaces gently with a soft damp cloth; use a neutral liquid soap with water for daily cleaning, dry any overspray.
    • ADA Compliance: Yes
    • Code Compliance: Code # FMLS60X: Certified with cUPC, NSF, CEC, IAPMO, CSA
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: No
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: No
    • Flow Restriction Options: 1.0 , 1.2 , 1.5 , 1.75, 2.2
    • Valve Material: Ceramic
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 7.94 INCH
    • Drain Hole Diameter: 1.75 INCH
    • Drain Depth Minimum: 1.50 INCH
    • Drain Depth Maximum: 1.75 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Control Valve Rough-in Depth Minimum: 5.75 INCH
    • Inlet Connection Size: 0.50 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Number of Handles: Two
    • Concealed / Exposed: Concealed
    • Drain Style: Push Touch
    • Inlet Connection Type: Female NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.2gpm
    • Leadtime: 8
