family name
Ludlow

Ludlow Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Cross Handles and Valve

SKU
LDLS60
In stock
$801.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Chrome Chrome
  • Nickel Nickel
  • Unlacquered Brass Unlacquered Brass

+

{"51294":{"price":"$891.00","price_unit":"Each","name":"Ludlow Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Cross Handles and Valve in Unlacquered Brass, 1.2gpm","price_gtm":"891.00","dimension11":"Yes","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Ludlow","variant":"Metal Finish:Unlacquered Brass","for_sale":1,"line_type":"Kit Parent","instock":false,"availability_message":null,"sku":"07-15366-86759","default":false,"id":"51294"},"51598":{"price":"$801.00","price_unit":"Each","name":"Ludlow Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Cross Handles and Valve in Chrome, 1.2gpm","price_gtm":"801.00","dimension11":"Yes","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Ludlow","variant":"Metal Finish:Chrome","for_sale":1,"line_type":"Kit Parent","instock":true,"availability_message":null,"sku":"07-50659-00819","default":false,"id":"51598"},"51599":{"price":"$877.00","price_unit":"Each","name":"Ludlow Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Cross Handles and Valve in Nickel, 1.2gpm","price_gtm":"877.00","dimension11":"Yes","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Ludlow","variant":"Metal Finish:Nickel","for_sale":1,"line_type":"Kit Parent","instock":true,"availability_message":null,"sku":"07-99423-85733","default":true,"id":"51599"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["51598"],"for_sale":1,"price":801},{"id":"5","label":"Nickel","products":["51599"],"for_sale":1,"price":877},{"id":"19","label":"Unlacquered Brass","products":["51294"],"for_sale":1,"price":891}],"position":"0"}},"optionProducts":{"143":{"5":["51599"],"3":["51598"],"19":["51294"]}},"template":"$<%- data.price %>","optionPrices":{"51294":{"oldPrice":{"amount":"891"},"basePrice":{"amount":"891"},"finalPrice":{"amount":"891"}},"51598":{"oldPrice":{"amount":"801"},"basePrice":{"amount":"801"},"finalPrice":{"amount":"801"}},"51599":{"oldPrice":{"amount":"877"},"basePrice":{"amount":"877"},"finalPrice":{"amount":"877"}}},"prices":{"oldPrice":{"amount":"801"},"basePrice":{"amount":"801"},"finalPrice":{"amount":"801"}},"productId":"51113","chooseText":"Choose an Option","images":[],"index":{"51294":{"143":"19"},"51598":{"143":"3"},"51599":{"143":"5"}}}
Request Information

Item Details

  • Ludlow COLLECTION

    A touch of classic Americana. Our fresh take on iconic industrial design has clean lines and dimensional details, including exposed screws and square plates.

  • FEATURES
    • Push touch USA style drain included.
    • This item is stocked in a Chrome, Nickel and Unlacquered Brass finishes.
    • Cross Handles
    • Standard flow rate is 1.2gpm (4.5 L/min) and meets State of California requirements. Also available in other flow options. Contact a sales associate for details.
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • ADA Compliance: Yes
    • Code Compliance: Code # LDLS60: CEC
    • Escutcheon Primary Material: Brass
    • Drain Assembly Materials: Brass
    • Flow Restriction Options: 1.0 , 1.2 , 1.5 , 1.75, 2.2
    • Valve Material: Brass, Ceramic
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 7.50 INCH
    • Drain Depth Minimum: 1.50 INCH
    • Drain Depth Maximum: 2.00 INCH
    • Water Pressure Maximum: 80.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Control Valve Rough-in Depth Minimum: 5.50 INCH
    • Inlet Connection Size: 0.50 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Installation Requirements or Notes: Includes Valve: GULV27
    • Drain Style: USA Push Touch
    • Inlet Connection Type: Female NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.2gpm
    • Leadtime: 12
    • ADA Compliance: Yes
    • Code Compliance: Code # LDLS60: CEC
    • Escutcheon Primary Material: Brass
    • Drain Assembly Materials: Brass
    • Flow Restriction Options: 1.0 , 1.2 , 1.5 , 1.75, 2.2
    • Valve Material: Brass, Ceramic
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 7.50 INCH
    • Drain Depth Minimum: 1.50 INCH
    • Drain Depth Maximum: 2.00 INCH
    • Water Pressure Maximum: 80.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Control Valve Rough-in Depth Minimum: 5.50 INCH
    • Inlet Connection Size: 0.50 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Installation Requirements or Notes: Includes Valve: GULV27
    • Drain Style: USA Push Touch
    • Inlet Connection Type: Female NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.2gpm
    • Leadtime: 12
    • ADA Compliance: Yes
    • Code Compliance: Code # LDLS60: CEC
    • Escutcheon Primary Material: Brass
    • Drain Assembly Materials: Brass
    • Flow Restriction Options: 1.0 , 1.2 , 1.5 , 1.75, 2.2
    • Valve Material: Brass, Ceramic
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 7.50 INCH
    • Drain Depth Minimum: 1.50 INCH
    • Drain Depth Maximum: 2.00 INCH
    • Water Pressure Maximum: 80.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Control Valve Rough-in Depth Minimum: 5.50 INCH
    • Inlet Connection Size: 0.50 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Installation Requirements or Notes: Includes Valve: GULV27
    • Drain Style: USA Push Touch
    • Inlet Connection Type: Female NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.2gpm
    • Leadtime: 12
Ludlow Low Profile Three Hole Wall Mounted Lavatory Faucet with Metal Cross Handles and Valve
