Aero

Aero Low Profile Concealed Tub Filler With Handshower and Metal Lever Handles

SKU
AETF89
In stock
$3,668.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Antique Brass Antique Brass
  • Antique Copper Antique Copper
  • Architectural Bronze Architectural Bronze
  • Burnished Nickel Burnished Nickel
  • Carbon Carbon
  • Chrome Chrome
  • Gold Gold
  • Matte Gold Matte Gold
  • Matte Nickel Matte Nickel
  • Nickel Nickel
  • Shiny Copper Shiny Copper
  • Sovereign Sovereign
  • Unlacquered Brass Unlacquered Brass

+

{"14641":{"price":"$6,782.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Architectural Bronze","price_gtm":"6782.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Architectural Bronze","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-16478-18539","default":false,"id":"14641"},"14649":{"price":"$6,585.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Shiny Copper","price_gtm":"6585.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Shiny Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-22583-18432","default":false,"id":"14649"},"35783":{"price":"$4,842.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Burnished Nickel","price_gtm":"4842.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Burnished Nickel","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-28639-49804","default":false,"id":"35783"},"14640":{"price":"$5,987.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Antique Brass","price_gtm":"5987.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Antique Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-35879-42269","default":false,"id":"14640"},"14761":{"price":"$3,668.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Chrome","price_gtm":"3668.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Chrome","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"09-47014-05547","default":false,"id":"14761"},"14652":{"price":"$4,619.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Unlacquered Brass","price_gtm":"4619.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Unlacquered Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-50277-52531","default":false,"id":"14652"},"14646":{"price":"$9,279.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Matte Gold","price_gtm":"9279.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Matte Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-70984-87093","default":false,"id":"14646"},"35784":{"price":"$5,244.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Carbon","price_gtm":"5244.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Carbon","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-74469-27697","default":false,"id":"35784"},"14763":{"price":"$4,045.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Nickel","price_gtm":"4045.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Nickel","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"09-80501-22487","default":true,"id":"14763"},"14651":{"price":"$6,585.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Sovereign","price_gtm":"6585.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Sovereign","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-87951-47425","default":false,"id":"14651"},"14644":{"price":"$9,279.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Gold","price_gtm":"9279.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-89061-86924","default":false,"id":"14644"},"14638":{"price":"$6,585.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Antique Copper","price_gtm":"6585.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Antique Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-90686-80786","default":false,"id":"14638"},"14762":{"price":"$4,372.00","price_unit":"Each","name":"Aero Low Profile Concealed Tub Filler with 2.5gpm Handshower and Metal Lever Handles in Matte Nickel","price_gtm":"4372.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Bathtub Faucets","category":"Fittings & Fixtures","family-name":"Aero","variant":"Metal Finish:Matte Nickel","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-91734-95777","default":false,"id":"14762"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["14761"],"for_sale":0,"price":3668},{"id":"5","label":"Nickel","products":["14763"],"for_sale":0,"price":4045},{"id":"6","label":"Matte Nickel","products":["14762"],"for_sale":0,"price":4372},{"id":"19","label":"Unlacquered Brass","products":["14652"],"for_sale":0,"price":4619},{"id":"406","label":"Burnished Nickel","products":["35783"],"for_sale":0,"price":4842},{"id":"249","label":"Carbon","products":["35784"],"for_sale":0,"price":5244},{"id":"14","label":"Antique Brass","products":["14640"],"for_sale":0,"price":5987},{"id":"13","label":"Antique Copper","products":["14638"],"for_sale":0,"price":6585},{"id":"17","label":"Shiny Copper","products":["14649"],"for_sale":0,"price":6585},{"id":"18","label":"Sovereign","products":["14651"],"for_sale":0,"price":6585},{"id":"8","label":"Architectural Bronze","products":["14641"],"for_sale":0,"price":6782},{"id":"15","label":"Gold","products":["14644"],"for_sale":0,"price":9279},{"id":"16","label":"Matte Gold","products":["14646"],"for_sale":0,"price":9279}],"position":"0"}},"optionProducts":{"143":{"14":["14640"],"5":["14763"],"406":["35783"],"249":["35784"],"6":["14762"],"17":["14649"],"16":["14646"],"13":["14638"],"8":["14641"],"19":["14652"],"15":["14644"],"3":["14761"],"18":["14651"]}},"template":"$<%- data.price %>","optionPrices":{"14641":{"oldPrice":{"amount":"6782"},"basePrice":{"amount":"6782"},"finalPrice":{"amount":"6782"}},"14649":{"oldPrice":{"amount":"6585"},"basePrice":{"amount":"6585"},"finalPrice":{"amount":"6585"}},"35783":{"oldPrice":{"amount":"4842"},"basePrice":{"amount":"4842"},"finalPrice":{"amount":"4842"}},"14640":{"oldPrice":{"amount":"5987"},"basePrice":{"amount":"5987"},"finalPrice":{"amount":"5987"}},"14761":{"oldPrice":{"amount":"3668"},"basePrice":{"amount":"3668"},"finalPrice":{"amount":"3668"}},"14652":{"oldPrice":{"amount":"4619"},"basePrice":{"amount":"4619"},"finalPrice":{"amount":"4619"}},"14646":{"oldPrice":{"amount":"9279"},"basePrice":{"amount":"9279"},"finalPrice":{"amount":"9279"}},"35784":{"oldPrice":{"amount":"5244"},"basePrice":{"amount":"5244"},"finalPrice":{"amount":"5244"}},"14763":{"oldPrice":{"amount":"4045"},"basePrice":{"amount":"4045"},"finalPrice":{"amount":"4045"}},"14651":{"oldPrice":{"amount":"6585"},"basePrice":{"amount":"6585"},"finalPrice":{"amount":"6585"}},"14644":{"oldPrice":{"amount":"9279"},"basePrice":{"amount":"9279"},"finalPrice":{"amount":"9279"}},"14638":{"oldPrice":{"amount":"6585"},"basePrice":{"amount":"6585"},"finalPrice":{"amount":"6585"}},"14762":{"oldPrice":{"amount":"4372"},"basePrice":{"amount":"4372"},"finalPrice":{"amount":"4372"}}},"prices":{"oldPrice":{"amount":"3668"},"basePrice":{"amount":"3668"},"finalPrice":{"amount":"3668"}},"productId":"46429","chooseText":"Choose an Option","images":[],"index":{"14641":{"143":"8"},"14649":{"143":"17"},"35783":{"143":"406"},"14640":{"143":"14"},"14761":{"143":"3"},"14652":{"143":"19"},"14646":{"143":"16"},"35784":{"143":"249"},"14763":{"143":"5"},"14651":{"143":"18"},"14644":{"143":"15"},"14638":{"143":"13"},"14762":{"143":"6"}}}
Request Information

Item Details

  • Aero COLLECTION

    Inspired by the stepped detail of 19th century telescopes, Aero is a combination of historical reference with a contemporary temperament. The result is original and modern, bringing a look of updated elegance.

  • FEATURES
    • Metal lever handles
    • Lift knob located on top of spout to divert water between tub and handshower.
    • Features signature stepped and gadrooned details on escutcheons and edge of spout
    • Stocked in Chrome and Nickel
    • Unrestricted flow for tub spout. Stocked in 2.5gpm (9.5L/min) flow rate for handshower. Alternate flow regulation of 1.75gpm (6.6/min) also availble as special order
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • Care and Cleaning Summary: To clean the finish, wipe gently with a soft damp cloth and then with a soft dry towel. A mild soap solution can be used for daily cleaning.
    • ADA Compliance: Yes
    • Code Compliance: Code # AETU89: ASME A112.18.1, CSA B125, IAPMO, State of MA
    • Suggested Application: Bath
    • Adjustable Levelers / Feet: No
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: No
    • Integrated Sensor Disk: No
    • Safety Shutoff: No
    • Spout Swivel: No
    • Spray Included in Unit: No
    • Flow Restriction Options: 2.5, 2.0, 1.75, 1.5, 0.92
    • Handshower Hose Material: Brass
    • Valve Material: Ceramic
    • Diameter of Head: 2.00 INCH
    • Handshower / Spray Hose Length: 79.00 INCH
    • Deck Thickness Maximum: 1.63 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 9.50 INCH
    • Unrestricted Maximum Flow at 45PSI: 9.50 GPM
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 10.00 INCH
    • Handle Spread Maximum: 12.00 INCH
    • Pivot: No
    • Number of Handles: Two
    • Flexible Connections: No
    • Concealed / Exposed: Concealed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT Adapter
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Leadtime: 10
