family name
Dash

Dash Deck Mounted Exposed Tub Filler with Metal Handshower and Cross Handles

SKU
DSXT40
$3,242.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Antique Brass Antique Brass
  • Antique Copper Antique Copper
  • Architectural Bronze Architectural Bronze
  • Burnished Brass Burnished Brass
  • Burnished Nickel Burnished Nickel
  • Carbon Carbon
  • Chrome Chrome
  • Gold Gold
  • Matte Gold Matte Gold
  • Matte Nickel Matte Nickel
  • Nickel Nickel
  • Pewter Pewter
  • Shadow Shadow
  • Shiny Copper Shiny Copper
  • Sovereign Sovereign
  • Unlacquered Brass Unlacquered Brass
  • Vintage Brass Vintage Brass

+

{"55014":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-41723-02290","default":false,"id":"55014"},"55010":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-78863-42980","default":false,"id":"55010"},"59981":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-96149-67155","default":false,"id":"59981"},"59993":{"price":"$4,315.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-65936-48513","default":false,"id":"59993"},"55020":{"price":"$4,279.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-83349-51653","default":false,"id":"55020"},"59991":{"price":"$4,637.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-55131-93827","default":false,"id":"59991"},"59986":{"price":"$3,242.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-27731-60548","default":true,"id":"59986"},"55026":{"price":"$8,916.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-52834-78121","default":false,"id":"55026"},"59988":{"price":"$8,951.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-93232-79664","default":false,"id":"59988"},"59985":{"price":"$3,728.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-83511-68015","default":false,"id":"59985"},"59987":{"price":"$3,566.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-90510-43770","default":false,"id":"59987"},"55022":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-87696-80545","default":false,"id":"55022"},"59995":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-85594-09725","default":false,"id":"59995"},"59982":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-07946-45703","default":false,"id":"59982"},"59989":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-74622-50453","default":false,"id":"59989"},"55013":{"price":"$3,631.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":"Available Early 2019","sku":"09-75434-02315","default":false,"id":"55013"},"59994":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-88046-48726","default":false,"id":"59994"},"55019":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-74031-52016","default":false,"id":"55019"},"59990":{"price":"$4,279.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-35682-77114","default":false,"id":"59990"},"59984":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-41573-33858","default":false,"id":"59984"},"59983":{"price":"$3,631.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-06638-72727","default":false,"id":"59983"},"59980":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-50695-27561","default":false,"id":"59980"},"55015":{"price":"$3,728.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":"Available Early 2019","sku":"09-02245-40474","default":false,"id":"55015"},"59996":{"price":"$8,916.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-29041-41733","default":false,"id":"59996"},"55024":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-49305-90464","default":false,"id":"55024"},"55016":{"price":"$3,242.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":"Available Early 2019","sku":"09-07215-14550","default":false,"id":"55016"},"55018":{"price":"$8,951.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-35586-75225","default":false,"id":"55018"},"55021":{"price":"$4,637.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-48116-01769","default":false,"id":"55021"},"55012":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-03949-48608","default":false,"id":"55012"},"59992":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-33696-28498","default":false,"id":"59992"},"55023":{"price":"$4,315.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-06558-73034","default":false,"id":"55023"},"55025":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-40722-40459","default":false,"id":"55025"},"55017":{"price":"$3,566.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":"Available Early 2019","sku":"09-83215-42472","default":false,"id":"55017"},"55011":{"price":"$4,458.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-94160-66041","default":false,"id":"55011"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["59986","55016"],"for_sale":0,"price":3242},{"id":"5","label":"Nickel","products":["59987","55017"],"for_sale":0,"price":3566},{"id":"19","label":"Unlacquered Brass","products":["55013","59983"],"for_sale":0,"price":3631},{"id":"6","label":"Matte Nickel","products":["59985","55015"],"for_sale":0,"price":3728},{"id":"406","label":"Burnished Nickel","products":["55020","59990"],"for_sale":0,"price":4279},{"id":"495","label":"Burnished Brass","products":["59993","55023"],"for_sale":0,"price":4315},{"id":"14","label":"Antique Brass","products":["55014","59984"],"for_sale":0,"price":4458},{"id":"13","label":"Antique Copper","products":["55010","59980"],"for_sale":0,"price":4458},{"id":"8","label":"Architectural Bronze","products":["59981","55011"],"for_sale":0,"price":4458},{"id":"450","label":"Pewter","products":["55022","59992"],"for_sale":0,"price":4458},{"id":"2461","label":"Shadow","products":["59995","55025"],"for_sale":0,"price":4458},{"id":"17","label":"Shiny Copper","products":["59982","55012"],"for_sale":0,"price":4458},{"id":"18","label":"Sovereign","products":["59989","55019"],"for_sale":0,"price":4458},{"id":"672","label":"Vintage Brass","products":["59994","55024"],"for_sale":0,"price":4458},{"id":"249","label":"Carbon","products":["59991","55021"],"for_sale":0,"price":4637},{"id":"15","label":"Gold","products":["55026","59996"],"for_sale":0,"price":8916},{"id":"16","label":"Matte Gold","products":["59988","55018"],"for_sale":0,"price":8951}],"position":"0"}},"optionProducts":{"143":{"14":["55014","59984"],"13":["55010","59980"],"8":["59981","55011"],"495":["59993","55023"],"406":["55020","59990"],"249":["59991","55021"],"3":["59986","55016"],"15":["55026","59996"],"16":["59988","55018"],"6":["59985","55015"],"5":["59987","55017"],"450":["55022","59992"],"2461":["59995","55025"],"17":["59982","55012"],"18":["59989","55019"],"19":["55013","59983"],"672":["59994","55024"]}},"template":"$<%- data.price %>","optionPrices":{"55014":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55010":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59981":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59993":{"oldPrice":{"amount":"4315"},"basePrice":{"amount":"4315"},"finalPrice":{"amount":"4315"}},"55020":{"oldPrice":{"amount":"4279"},"basePrice":{"amount":"4279"},"finalPrice":{"amount":"4279"}},"59991":{"oldPrice":{"amount":"4637"},"basePrice":{"amount":"4637"},"finalPrice":{"amount":"4637"}},"59986":{"oldPrice":{"amount":"3242"},"basePrice":{"amount":"3242"},"finalPrice":{"amount":"3242"}},"55026":{"oldPrice":{"amount":"8916"},"basePrice":{"amount":"8916"},"finalPrice":{"amount":"8916"}},"59988":{"oldPrice":{"amount":"8951"},"basePrice":{"amount":"8951"},"finalPrice":{"amount":"8951"}},"59985":{"oldPrice":{"amount":"3728"},"basePrice":{"amount":"3728"},"finalPrice":{"amount":"3728"}},"59987":{"oldPrice":{"amount":"3566"},"basePrice":{"amount":"3566"},"finalPrice":{"amount":"3566"}},"55022":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59995":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59982":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59989":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55013":{"oldPrice":{"amount":"3631"},"basePrice":{"amount":"3631"},"finalPrice":{"amount":"3631"}},"59994":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55019":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59990":{"oldPrice":{"amount":"4279"},"basePrice":{"amount":"4279"},"finalPrice":{"amount":"4279"}},"59984":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59983":{"oldPrice":{"amount":"3631"},"basePrice":{"amount":"3631"},"finalPrice":{"amount":"3631"}},"59980":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55015":{"oldPrice":{"amount":"3728"},"basePrice":{"amount":"3728"},"finalPrice":{"amount":"3728"}},"59996":{"oldPrice":{"amount":"8916"},"basePrice":{"amount":"8916"},"finalPrice":{"amount":"8916"}},"55024":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55016":{"oldPrice":{"amount":"3242"},"basePrice":{"amount":"3242"},"finalPrice":{"amount":"3242"}},"55018":{"oldPrice":{"amount":"8951"},"basePrice":{"amount":"8951"},"finalPrice":{"amount":"8951"}},"55021":{"oldPrice":{"amount":"4637"},"basePrice":{"amount":"4637"},"finalPrice":{"amount":"4637"}},"55012":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"59992":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55023":{"oldPrice":{"amount":"4315"},"basePrice":{"amount":"4315"},"finalPrice":{"amount":"4315"}},"55025":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}},"55017":{"oldPrice":{"amount":"3566"},"basePrice":{"amount":"3566"},"finalPrice":{"amount":"3566"}},"55011":{"oldPrice":{"amount":"4458"},"basePrice":{"amount":"4458"},"finalPrice":{"amount":"4458"}}},"prices":{"oldPrice":{"amount":"3242"},"basePrice":{"amount":"3242"},"finalPrice":{"amount":"3242"}},"productId":"55219","chooseText":"Choose an Option","images":[],"index":{"55014":{"143":"14"},"55010":{"143":"13"},"59981":{"143":"8"},"59993":{"143":"495"},"55020":{"143":"406"},"59991":{"143":"249"},"59986":{"143":"3"},"55026":{"143":"15"},"59988":{"143":"16"},"59985":{"143":"6"},"59987":{"143":"5"},"55022":{"143":"450"},"59995":{"143":"2461"},"59982":{"143":"17"},"59989":{"143":"18"},"55013":{"143":"19"},"59994":{"143":"672"},"55019":{"143":"18"},"59990":{"143":"406"},"59984":{"143":"14"},"59983":{"143":"19"},"59980":{"143":"13"},"55015":{"143":"6"},"59996":{"143":"15"},"55024":{"143":"672"},"55016":{"143":"3"},"55018":{"143":"16"},"55021":{"143":"249"},"55012":{"143":"17"},"59992":{"143":"450"},"55023":{"143":"495"},"55025":{"143":"2461"},"55017":{"143":"5"},"55011":{"143":"8"}}}
Request Information

Item Details

  • Dash COLLECTION

    A blend of art and function, Dash pays homage to design elements of the 1930s with pared-down shapes, softened curves and minimal details.

  • FEATURES
    • Metal Cross Handle
    • Includes Required Unions for Mounting
    • Handshower hook features adjustability to pivot the handshower forwards or backwards
    • Stocked in Nickel, Chrome, Unlacquered Brass, and Matte Nickel finishes
    • Stocked in 2.5gpm (9.5 L/min) and 1.75gpm (6.6 L/min) for handshower. State of California requires 1.75gpm (6.6 L/min) to comply with their water conservation requirements. Other flow options are available to order, contact your sales associate or call 1 (800) 899-6757 for details.
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
