Dash

Dash Deck Mounted Exposed Tub Filler with Metal Handshower and Lever Handles

SKU
DSXT50
$3,228.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Antique Brass Antique Brass
  • Antique Copper Antique Copper
  • Architectural Bronze Architectural Bronze
  • Burnished Brass Burnished Brass
  • Burnished Nickel Burnished Nickel
  • Carbon Carbon
  • Chrome Chrome
  • Gold Gold
  • Matte Gold Matte Gold
  • Matte Nickel Matte Nickel
  • Nickel Nickel
  • Pewter Pewter
  • Shadow Shadow
  • Shiny Copper Shiny Copper
  • Sovereign Sovereign
  • Unlacquered Brass Unlacquered Brass
  • Vintage Brass Vintage Brass

+

{"55031":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-58009-13477","default":false,"id":"55031"},"59997":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-58949-74489","default":false,"id":"59997"},"55028":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-81810-09972","default":false,"id":"55028"},"55040":{"price":"$4,297.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-80799-39384","default":false,"id":"55040"},"60007":{"price":"$4,261.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-52596-45756","default":false,"id":"60007"},"55038":{"price":"$4,616.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-34116-04585","default":false,"id":"55038"},"55033":{"price":"$3,228.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":null,"sku":"09-18316-04028","default":true,"id":"55033"},"60013":{"price":"$8,877.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-76126-07908","default":false,"id":"60013"},"60005":{"price":"$8,912.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-34865-47220","default":false,"id":"60005"},"60002":{"price":"$3,712.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-18725-12810","default":false,"id":"60002"},"60004":{"price":"$3,551.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-26020-67669","default":false,"id":"60004"},"60009":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-87371-41632","default":false,"id":"60009"},"60012":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-82830-61258","default":false,"id":"60012"},"55029":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-28488-52850","default":false,"id":"55029"},"55036":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-54599-41805","default":false,"id":"55036"},"60000":{"price":"$3,615.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-86658-70861","default":false,"id":"60000"},"60011":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-95463-25553","default":false,"id":"60011"},"60008":{"price":"$4,616.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-27504-21374","default":false,"id":"60008"},"55039":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-86506-26799","default":false,"id":"55039"},"55041":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-05976-88351","default":false,"id":"55041"},"55035":{"price":"$8,912.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-07369-66132","default":false,"id":"55035"},"55027":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-50219-84145","default":false,"id":"55027"},"60010":{"price":"$4,297.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-37922-51745","default":false,"id":"60010"},"55042":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-70297-49331","default":false,"id":"55042"},"55037":{"price":"$4,261.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-49458-74159","default":false,"id":"55037"},"60003":{"price":"$3,228.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":"Available Early 2019","sku":"09-10991-27068","default":false,"id":"60003"},"60001":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-35184-73728","default":false,"id":"60001"},"59998":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-54470-96709","default":false,"id":"59998"},"55030":{"price":"$3,615.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":null,"sku":"09-82935-29001","default":false,"id":"55030"},"59999":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-22985-00480","default":false,"id":"59999"},"60006":{"price":"$4,439.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-51299-80400","default":false,"id":"60006"},"55032":{"price":"$3,712.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":null,"sku":"09-01961-53623","default":false,"id":"55032"},"55043":{"price":"$8,877.00","price_unit":"Each","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"09-55403-24033","default":false,"id":"55043"},"55034":{"price":"$3,551.00","price_unit":"Each","for_sale":0,"line_type":"Stock Inventory Item","instock":false,"availability_message":null,"sku":"09-20812-61709","default":false,"id":"55034"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["55033","60003"],"for_sale":0,"price":3228},{"id":"5","label":"Nickel","products":["60004","55034"],"for_sale":0,"price":3551},{"id":"19","label":"Unlacquered Brass","products":["60000","55030"],"for_sale":0,"price":3615},{"id":"6","label":"Matte Nickel","products":["60002","55032"],"for_sale":0,"price":3712},{"id":"406","label":"Burnished Nickel","products":["60007","55037"],"for_sale":0,"price":4261},{"id":"495","label":"Burnished Brass","products":["55040","60010"],"for_sale":0,"price":4297},{"id":"14","label":"Antique Brass","products":["55031","60001"],"for_sale":0,"price":4439},{"id":"13","label":"Antique Copper","products":["59997","55027"],"for_sale":0,"price":4439},{"id":"8","label":"Architectural Bronze","products":["55028","59998"],"for_sale":0,"price":4439},{"id":"450","label":"Pewter","products":["60009","55039"],"for_sale":0,"price":4439},{"id":"2461","label":"Shadow","products":["60012","55042"],"for_sale":0,"price":4439},{"id":"17","label":"Shiny Copper","products":["55029","59999"],"for_sale":0,"price":4439},{"id":"18","label":"Sovereign","products":["55036","60006"],"for_sale":0,"price":4439},{"id":"672","label":"Vintage Brass","products":["60011","55041"],"for_sale":0,"price":4439},{"id":"249","label":"Carbon","products":["55038","60008"],"for_sale":0,"price":4616},{"id":"15","label":"Gold","products":["60013","55043"],"for_sale":0,"price":8877},{"id":"16","label":"Matte Gold","products":["60005","55035"],"for_sale":0,"price":8912}],"position":"0"}},"optionProducts":{"143":{"14":["55031","60001"],"13":["59997","55027"],"8":["55028","59998"],"495":["55040","60010"],"406":["60007","55037"],"249":["55038","60008"],"3":["55033","60003"],"15":["60013","55043"],"16":["60005","55035"],"6":["60002","55032"],"5":["60004","55034"],"450":["60009","55039"],"2461":["60012","55042"],"17":["55029","59999"],"18":["55036","60006"],"19":["60000","55030"],"672":["60011","55041"]}},"template":"$<%- data.price %>","optionPrices":{"55031":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"59997":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55028":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55040":{"oldPrice":{"amount":"4297"},"basePrice":{"amount":"4297"},"finalPrice":{"amount":"4297"}},"60007":{"oldPrice":{"amount":"4261"},"basePrice":{"amount":"4261"},"finalPrice":{"amount":"4261"}},"55038":{"oldPrice":{"amount":"4616"},"basePrice":{"amount":"4616"},"finalPrice":{"amount":"4616"}},"55033":{"oldPrice":{"amount":"3228"},"basePrice":{"amount":"3228"},"finalPrice":{"amount":"3228"}},"60013":{"oldPrice":{"amount":"8877"},"basePrice":{"amount":"8877"},"finalPrice":{"amount":"8877"}},"60005":{"oldPrice":{"amount":"8912"},"basePrice":{"amount":"8912"},"finalPrice":{"amount":"8912"}},"60002":{"oldPrice":{"amount":"3712"},"basePrice":{"amount":"3712"},"finalPrice":{"amount":"3712"}},"60004":{"oldPrice":{"amount":"3551"},"basePrice":{"amount":"3551"},"finalPrice":{"amount":"3551"}},"60009":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"60012":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55029":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55036":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"60000":{"oldPrice":{"amount":"3615"},"basePrice":{"amount":"3615"},"finalPrice":{"amount":"3615"}},"60011":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"60008":{"oldPrice":{"amount":"4616"},"basePrice":{"amount":"4616"},"finalPrice":{"amount":"4616"}},"55039":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55041":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55035":{"oldPrice":{"amount":"8912"},"basePrice":{"amount":"8912"},"finalPrice":{"amount":"8912"}},"55027":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"60010":{"oldPrice":{"amount":"4297"},"basePrice":{"amount":"4297"},"finalPrice":{"amount":"4297"}},"55042":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55037":{"oldPrice":{"amount":"4261"},"basePrice":{"amount":"4261"},"finalPrice":{"amount":"4261"}},"60003":{"oldPrice":{"amount":"3228"},"basePrice":{"amount":"3228"},"finalPrice":{"amount":"3228"}},"60001":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"59998":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55030":{"oldPrice":{"amount":"3615"},"basePrice":{"amount":"3615"},"finalPrice":{"amount":"3615"}},"59999":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"60006":{"oldPrice":{"amount":"4439"},"basePrice":{"amount":"4439"},"finalPrice":{"amount":"4439"}},"55032":{"oldPrice":{"amount":"3712"},"basePrice":{"amount":"3712"},"finalPrice":{"amount":"3712"}},"55043":{"oldPrice":{"amount":"8877"},"basePrice":{"amount":"8877"},"finalPrice":{"amount":"8877"}},"55034":{"oldPrice":{"amount":"3551"},"basePrice":{"amount":"3551"},"finalPrice":{"amount":"3551"}}},"prices":{"oldPrice":{"amount":"3228"},"basePrice":{"amount":"3228"},"finalPrice":{"amount":"3228"}},"productId":"55220","chooseText":"Choose an Option","images":[],"index":{"55031":{"143":"14"},"59997":{"143":"13"},"55028":{"143":"8"},"55040":{"143":"495"},"60007":{"143":"406"},"55038":{"143":"249"},"55033":{"143":"3"},"60013":{"143":"15"},"60005":{"143":"16"},"60002":{"143":"6"},"60004":{"143":"5"},"60009":{"143":"450"},"60012":{"143":"2461"},"55029":{"143":"17"},"55036":{"143":"18"},"60000":{"143":"19"},"60011":{"143":"672"},"60008":{"143":"249"},"55039":{"143":"450"},"55041":{"143":"672"},"55035":{"143":"16"},"55027":{"143":"13"},"60010":{"143":"495"},"55042":{"143":"2461"},"55037":{"143":"406"},"60003":{"143":"3"},"60001":{"143":"14"},"59998":{"143":"8"},"55030":{"143":"19"},"59999":{"143":"17"},"60006":{"143":"18"},"55032":{"143":"6"},"55043":{"143":"15"},"55034":{"143":"5"}}}
Request Information

Item Details

  • Dash COLLECTION

    A blend of art and function, Dash pays homage to design elements of the 1930s with pared-down shapes, softened curves and minimal details.

  • FEATURES
    • Metal Lever Handle
    • Includes Required Unions for Mounting
    • Handshower hook features adjustability to pivot the handshower forwards or backwards
    • Stocked in Nickel, Chrome, Unlacquered Brass, and Matte Nickel finishes
    • Stocked in 2.5gpm (9.5 L/min) and 1.75gpm (6.6 L/min) for handshower. State of California requires 1.75gpm (6.6 L/min) to comply with their water conservation requirements. Other flow options are available to order, contact your sales associate or call 1 (800) 899-6757 for details.
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.75gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: Yes
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: Yes
    • Flow Restriction Options: 2.5, 2.2, 2.0, 1.75, 1.5, 1.2, 0.92
    • Valve Material: Ceramic
    • Diameter of Head: 2.38 INCH
    • Handshower / Spray Hose Length: 59.00 INCH
    • Deck Thickness Maximum: 1.69 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 8.31 INCH
    • Deck Thickness Minimum: 0.00 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.75 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 8.00 INCH
    • Pivot: Yes
    • Number of Handles: Two
    • Spout Shape: Gooseneck
    • Installation Requirements or Notes: Pivot, Restricted Maximum Flow Rate and Flow Restriction Options Apply Only to the Handshower.
    • Concealed / Exposed: Exposed
    • Handshower Handle Color and Material: Metal
    • Inlet Connection Type: Male NPT
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 2.5gpm
Dash Deck Mounted Exposed Tub Filler with Metal Handshower and Lever Handles
More Information
family name Dash
Banner Block No
Group Surfaces No

REQUEST INFORMATION

Dash

Dash Deck Mounted Exposed Tub Filler with Metal Handshower and Lever Handles

STYLE: DSXT50 STOCK ITEM

  • Need technical support?
    Service portal
