Henry

Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles

SKU
HNLS10
In stock
$1,470.00
Product Options Color / Finish Options
Wishlist Icon ADD TO PROJECTS FOLDER Add to Project Folder
Locations Icon Print Page
Locations Icon Find a Showroom

Color / Finish Options

  • Antique Brass Antique Brass
  • Antique Copper Antique Copper
  • Architectural Bronze Architectural Bronze
  • Burnished Brass Burnished Brass
  • Burnished Nickel Burnished Nickel
  • Carbon Carbon
  • Chrome Chrome
  • Gold Gold
  • Matte Gold Matte Gold
  • Matte Nickel Matte Nickel
  • Nickel Nickel
  • Pewter Pewter
  • Shiny Copper Shiny Copper
  • Sovereign Sovereign
  • Unlacquered Brass Unlacquered Brass
  • Vintage Brass Vintage Brass

+

{"38382":{"price":"$1,692.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Matte Nickel, 1.2gpm (4.5L\/min)","price_gtm":"1692.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Matte Nickel","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-38882-30823","default":false,"id":"38382"},"38384":{"price":"$1,598.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Nickel, 1.2gpm (4.5L\/min)","price_gtm":"1598.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Nickel","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-36598-22237","default":true,"id":"38384"},"38385":{"price":"$1,940.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Burnished Nickel, 1.2gpm (4.5L\/min)","price_gtm":"1940.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Burnished Nickel","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-57090-33616","default":false,"id":"38385"},"38380":{"price":"$2,344.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Antique Copper, 1.2gpm (4.5L\/min)","price_gtm":"2344.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Antique Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-38840-88914","default":false,"id":"38380"},"44121":{"price":"$1,957.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Burnished Brass, 1.2gpm (4.5L\/min)","price_gtm":"1957.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Burnished Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-27351-71150","default":false,"id":"44121"},"38376":{"price":"$2,625.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Sovereign, 1.2gpm (4.5L\/min)","price_gtm":"2625.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Sovereign","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-62744-32974","default":false,"id":"38376"},"38374":{"price":"$1,634.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Unlacquered Brass, 1.2gpm (4.5L\/min)","price_gtm":"1634.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Unlacquered Brass","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-82542-64953","default":false,"id":"38374"},"38377":{"price":"$4,053.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Gold, 1.2gpm (4.5L\/min)","price_gtm":"4053.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-43979-44684","default":false,"id":"38377"},"38378":{"price":"$2,625.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Shiny Copper, 1.2gpm (4.5L\/min)","price_gtm":"2625.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Shiny Copper","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-77124-76441","default":false,"id":"38378"},"38381":{"price":"$2,344.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Architectural Bronze, 1.2gpm (4.5L\/min)","price_gtm":"2344.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Architectural Bronze","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-92822-83847","default":false,"id":"38381"},"38379":{"price":"$1,470.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Chrome, 1.2gpm (4.5L\/min)","price_gtm":"1470.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Chrome","for_sale":0,"line_type":"Stock Inventory Item","instock":true,"availability_message":null,"sku":"07-60269-81085","default":false,"id":"38379"},"38383":{"price":"$4,053.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Matte Gold, 1.2gpm (4.5L\/min)","price_gtm":"4053.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Matte Gold","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-97249-19161","default":false,"id":"38383"},"44123":{"price":"$2,022.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Vintage Brass, 1.2gpm (4.5L\/min)","price_gtm":"2022.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Vintage Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-51773-35310","default":false,"id":"44123"},"44122":{"price":"$2,022.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Pewter, 1.2gpm (4.5L\/min)","price_gtm":"2022.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Pewter","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-60003-05265","default":false,"id":"44122"},"38375":{"price":"$2,344.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Antique Brass, 1.2gpm (4.5L\/min)","price_gtm":"2344.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Antique Brass","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-29829-57814","default":false,"id":"38375"},"38386":{"price":"$2,103.00","price_unit":"Each","name":"Henry Low Profile Three Hole Deck Mounted Lavatory Faucet with Metal Lever Handles in Carbon, 1.2gpm (4.5L\/min)","price_gtm":"2103.00","dimension11":"No","brand":"Heritage","dimension12":"Bath","dimension13":"Faucets","category":"Fittings & Fixtures","family-name":"Henry","variant":"Metal Finish:Carbon","for_sale":0,"line_type":"Special Order","instock":true,"availability_message":null,"sku":"07-88302-22505","default":false,"id":"38386"}}
{"attributes":{"143":{"id":"143","code":"metal_finish","label":"Metal Finish","options":[{"id":"3","label":"Chrome","products":["38379"],"for_sale":0,"price":1470},{"id":"5","label":"Nickel","products":["38384"],"for_sale":0,"price":1598},{"id":"19","label":"Unlacquered Brass","products":["38374"],"for_sale":0,"price":1634},{"id":"6","label":"Matte Nickel","products":["38382"],"for_sale":0,"price":1692},{"id":"406","label":"Burnished Nickel","products":["38385"],"for_sale":0,"price":1940},{"id":"495","label":"Burnished Brass","products":["44121"],"for_sale":0,"price":1957},{"id":"450","label":"Pewter","products":["44122"],"for_sale":0,"price":2022},{"id":"672","label":"Vintage Brass","products":["44123"],"for_sale":0,"price":2022},{"id":"249","label":"Carbon","products":["38386"],"for_sale":0,"price":2103},{"id":"14","label":"Antique Brass","products":["38375"],"for_sale":0,"price":2344},{"id":"13","label":"Antique Copper","products":["38380"],"for_sale":0,"price":2344},{"id":"8","label":"Architectural Bronze","products":["38381"],"for_sale":0,"price":2344},{"id":"17","label":"Shiny Copper","products":["38378"],"for_sale":0,"price":2625},{"id":"18","label":"Sovereign","products":["38376"],"for_sale":0,"price":2625},{"id":"15","label":"Gold","products":["38377"],"for_sale":0,"price":4053},{"id":"16","label":"Matte Gold","products":["38383"],"for_sale":0,"price":4053}],"position":"0"}},"optionProducts":{"143":{"8":["38381"],"14":["38375"],"13":["38380"],"17":["38378"],"450":["44122"],"406":["38385"],"15":["38377"],"672":["44123"],"19":["38374"],"16":["38383"],"5":["38384"],"18":["38376"],"3":["38379"],"6":["38382"],"249":["38386"],"495":["44121"]}},"template":"$<%- data.price %>","optionPrices":{"38382":{"oldPrice":{"amount":"1692"},"basePrice":{"amount":"1692"},"finalPrice":{"amount":"1692"}},"38384":{"oldPrice":{"amount":"1598"},"basePrice":{"amount":"1598"},"finalPrice":{"amount":"1598"}},"38385":{"oldPrice":{"amount":"1940"},"basePrice":{"amount":"1940"},"finalPrice":{"amount":"1940"}},"38380":{"oldPrice":{"amount":"2344"},"basePrice":{"amount":"2344"},"finalPrice":{"amount":"2344"}},"44121":{"oldPrice":{"amount":"1957"},"basePrice":{"amount":"1957"},"finalPrice":{"amount":"1957"}},"38376":{"oldPrice":{"amount":"2625"},"basePrice":{"amount":"2625"},"finalPrice":{"amount":"2625"}},"38374":{"oldPrice":{"amount":"1634"},"basePrice":{"amount":"1634"},"finalPrice":{"amount":"1634"}},"38377":{"oldPrice":{"amount":"4053"},"basePrice":{"amount":"4053"},"finalPrice":{"amount":"4053"}},"38378":{"oldPrice":{"amount":"2625"},"basePrice":{"amount":"2625"},"finalPrice":{"amount":"2625"}},"38381":{"oldPrice":{"amount":"2344"},"basePrice":{"amount":"2344"},"finalPrice":{"amount":"2344"}},"38379":{"oldPrice":{"amount":"1470"},"basePrice":{"amount":"1470"},"finalPrice":{"amount":"1470"}},"38383":{"oldPrice":{"amount":"4053"},"basePrice":{"amount":"4053"},"finalPrice":{"amount":"4053"}},"44123":{"oldPrice":{"amount":"2022"},"basePrice":{"amount":"2022"},"finalPrice":{"amount":"2022"}},"44122":{"oldPrice":{"amount":"2022"},"basePrice":{"amount":"2022"},"finalPrice":{"amount":"2022"}},"38375":{"oldPrice":{"amount":"2344"},"basePrice":{"amount":"2344"},"finalPrice":{"amount":"2344"}},"38386":{"oldPrice":{"amount":"2103"},"basePrice":{"amount":"2103"},"finalPrice":{"amount":"2103"}}},"prices":{"oldPrice":{"amount":"1470"},"basePrice":{"amount":"1470"},"finalPrice":{"amount":"1470"}},"productId":"47175","chooseText":"Choose an Option","images":[],"index":{"38382":{"143":"6"},"38384":{"143":"5"},"38385":{"143":"406"},"38380":{"143":"13"},"44121":{"143":"495"},"38376":{"143":"18"},"38374":{"143":"19"},"38377":{"143":"15"},"38378":{"143":"17"},"38381":{"143":"8"},"38379":{"143":"3"},"38383":{"143":"16"},"44123":{"143":"672"},"44122":{"143":"450"},"38375":{"143":"14"},"38386":{"143":"249"}}}
Request Information

Item Details

  • Henry COLLECTION

    Influenced by the connection of industry and art Henry easily transitions between modern, traditional, utilitarian and classic settings.

  • FEATURES
    • Metal lever handles
    • Includes European size push touch drain
    • The manufacturing process encompasses casting, turning, forging, hand-fitting and hand polishing.
    • Stocked in Chrome, Nickel, Matte Nickel, and Unlacquered Brass
    • Available in 1.2gpm (4.5L/min) flow rate
    VIEW FULL COLLECTION

Technical Documents

Technical Details

    • ADA Compliance: Yes
    • Code Compliance: Code # HNLS10X: Complies with ASME A112.18.1/CSA B125.1, ASME A112.18.2 / CSA B125.2, NSF, CEC 61, ADA and 0.25% Weighted Average Lead Content. Certified with IAPMO, cUPC, NSF, CEC and State of MA.
    • Suggested Application: Bath
    • Escutcheon Primary Material: Brass
    • Anti-scald Protection: No
    • Hot Limit Safety Stop: No
    • Integrated Diverter: No
    • Integrated Spray: No
    • Spout Swivel: No
    • Spray Included in Unit: No
    • Flow Restriction Options: 1.0 , 1.2 , 1.5 , 1.75, 2.2
    • Valve Material: Ceramic
    • Deck Thickness Maximum: 1.63 INCH
    • Water Pressure Minimum: 20.00 PSI
    • Spout Reach: 5.75 INCH
    • Drain Hole Diameter: 1.75 INCH
    • Drain Depth Minimum: 0.38 INCH
    • Drain Depth Maximum: 2.63 INCH
    • Deck Thickness Minimum: 0.19 INCH
    • Water Pressure Maximum: 85.00 PSI
    • Water Pressure Recommended: 45.00 PSI
    • Inlet Connection Size: 0.50 INCH
    • Handle Spread Minimum: 8.00 INCH
    • Handle Spread Maximum: 12.00 INCH
    • Number of Handles: Two
    • Flexible Connections: No
    • Gland Cover Material: Metal
    • Concealed / Exposed: Concealed
    • Inlet Connection Type: Male with Supply Nut
    • Handle Turn Angle: Quarter Turn
    • Flow Rate: 1.2gpm
    • Leadtime: 14
